YoloBox-Pro

STATUS

Status

New

Availability

Available on order: 15 Business Days

Type of Encoder

Streaming Encoder

CONNECTIONS

Video inputs

HDMI x3
USB 3.0 x1

Video outputs

HDMI x1

Audio inputs

Jack 3.5mm x1
Jack 3.5mm x1
Embedded audio HDMI x1

Audio Output

Jack 3.5mm Stereo x1
2CH Embedded Audio HDMI x1

PC Connections

USB C
Ethernet
WiFi

GENERAL FEATURES

Max Resolution Supported

HD 720: 1280 x 720pixels (16:9 aspect ratio)
Full HD: 1920 x 1080pixels (16:9 aspect ratio)

Frames Supported

50P/60P @1280x720Pixel.
50i/50P/60i/60P @1920x1080Pixel.

Video Codecs

H.264

Internal Recording

SD Card (Expanded to 128G in FAT32 Format)

MORE SPECIFICATIONS

Extras

400nits Brightness.
Built-In Battery 10.000 mAh .
Built-In WiFi 5/Ethernet via Cable.
SIM Card Slot: Insert SIM Card to connect to Internet.
1/4" Screw Hole: Mount YoloBox Pro with camera.

Power

Through USB

No. of battery slots

1

Power Consumption

Input Voltage: 5-12V

Country of Origin

China

Warranty

1 Year

PHYSICAL

Total Dimensions (LxWxH)

21.8 x 12.9 x 2.7 cm

Total Weight

750 gr
