Decimator MultiViewer
DMON QUAD
MFR# DD-DMON-QUAD
BLK# 199-0017
in-Store Price: 359,37€ + VAT
Online Price: 344,99€ + VAT
- Multiviewer
- 4x 3G-SDI inputs
- 1x 3G-SDI & HDMI outputs
- Split Screen - Window scaling
4 x (3G/HD/SD)-SDI to HDMI Converters with 1 to 4 MultiViewer, Custom Layouts and 8 Channel Audio Meters
- Supports 3G level A and B on inputs and output, allowing conversion between 3G level A and B
- Low cost (3G/HD/SD)-SDI 1 to 4 Multi-Viewer or 4 to 1 input multiplexer
- Custom Layouts with various standard layouts
- 16 Character UMD overlay per window with individual enables, custom positioning and size
- 8 Channel Audio Metering overlay per window with individual enables, custom positioning and size
- Horizontal and/or Vertical image flipping per window
- Audio ID overlay
- Tallies can be applied to either Tally Boxes (Default) or Border
- Tally boxes allows for up to 4 Tallies per window
- Fast switching between inputs using Full-Screen scaling
- Selectable output format in both Full-Screen Multi-Viewer mode
- Low latency buffering for each input allowing non-synchronous inputs
- Linked (3G/HD/SD)-SDI and HDMI outputs
- 4 x (3G/HD/SD)-SDI inputs with auto detection (26 Formats supported in total)
- Each window is independent of the others, allowing any 3G/HD/SD format of any frame rate to be displayed simultaneously
- Variable aspect ratios per window
- In Pass-Through mode the selected input is passed through to both the (3G/HD/SD)-SDI and HDMI outputs
- The DMON-QUAD is a truly portable converter, that incorporates our easy to use LCD and button control system. This gives you easy access to most of the amazing features without using complicated LED/button control, dip switches or having to carry around a computer to change a simple setting.
- This unit also includes:
- GPI on RJ-45 connector for Tallies and Remote Switching
- RS422/485 on RJ-45 connector for Dynamic UMD and Tallies
- USB port for control and firmware updates
- Robust Aluminium box
- Metal Thread Locking DC Power Socket
- Power Supply, HDMI Cable and USB Cable
STATUS
- Status
- New
- Availability
- Available on order: 15 Business Days
- Multiviewer type
-
Quad Split
Multi Split with Free Windows scaling
- Available inputs
-
Up to 4 inputs
CONNECTIONS
- Video inputs
-
3G/HD/SD-SDI (BNC) x4
- Video outputs
-
3G-SDI x1
HDMI x1
- Audio inputs
-
Embedded audio SDI x4
- Audio outputs
-
Embedded Audio SDI x1
Embedded Audio HDMI x1
- PC Connections
-
USB
GPI
GENERAL FEATURES
- Max Resolution Supported
-
SD 480i NTSC
SD 576i PAL
HD 720: 1280 x 720pixels (16:9 aspect ratio)
Full HD: 1920 x 1080pixels (16:9 aspect ratio)
- Frames Supported
-
24P/25P/30P/50i/50P/60i/60P @1920x1080Pixel
50P/60P @1280x720
50i @720x576Pixel
60i @720x480Pixel
- Multiviewer Features
-
Quad Split
Full Screen
Free Scaling Windows
Audio Meter
MORE SPECIFICATIONS
- Extras
-
Split Screen.
Quad split.
Window scaling.
- Power
-
Power adapter
- Power Consumption
-
Not specified (5-32V)
- Country of Origin
-
USA
- Warranty
- 1 Year
PHYSICAL
- Total Dimensions (LxWxH)
- 7.9 x 12.3 x 2.9 cm
- Total Weight
- 1 kg
- Multiviewer
-
