SmallHD Monitor

Vision 24 4K HDR

MFR# MON-VISION-24 BLK# 574-0147

in-Store Price: 8.781,16€ + VAT

Online Price: 8.429,91€ + VAT

Production Desktop Monitor
24" LCD IPS
12G-SDI & HDMI Input/Output
4096 x 2160 Resolution

Not in stock
Available on order: 15 Business Days

Vision 24 allows you to see as your camera sees. Engineered to equal modern sensors’ increased sensitivity to highlight and lowlight image retention. Powered by SmallHDR, a proprietary Full-Array Local Dimming (FALD) hardware that enables nuanced control of over 2100 individual LED zones, rendering hyper-sharp contrasts with deep blacks, crisp highlights, and a stunning 10-bit color depth. Ideal for use in any production environment where HDR monitoring is a necessity, Vision 24 provides the added security that every detail is captured.

Product Highlights

24.1in/61cm Full-Array Local Dimming (FALD)
1000nits
1,000,000:1 Contrast Ratio
10-bit Color Depth
2176 Zone high-density FALD Backlight
4096x2160 Resolution
Weight: 19.7lbs / 8.9kg (with handle & feet)

Key Platform Highlights

PageOS 4 software platform
4K HDR waveform and scopes
Dual & Quad-view*
Color Pipe HDR color rendering
Monitor Calibration Wizard

Small4K™ Video Processing Architecture
Inputs: 4x 12G-SDI , 1x HDMI 2.0
Outputs: 4x 12G-SDI, 1x HDMI 2.0*

Unibody Smart Chassis
Dovetail Mounting Rail for battery and accessory mounting
Interchangeable mounting points
2x 2-pin accessory power outputs

Power: Hot-swappable dual inputs: 1x 3-pin XLR, 1x Dual-GM/VM Battery Plate (sold separately)

Source: https://store.smallhd.com/collections/all/products/vision24?product_id=5102433566853&variant_id=34389898133637&product_handle=vision24

STATUS

Status: New
Availability: Available on order: 15 Business Days
Monitor Type: Preview Monitor

PANEL

Panel Size: 24"
Panel Type: LCD
Panel Resolution: 4K: 4096 x 2160pixels(16:9 aspect ratio)
Pixel Density (PPI): 93
Panel Aspect Ratio: 16:9
Input Resolutions: HD 1080: 1920x1080pixels(16:9 aspect ratio)
UHD: 3840x2160pixels
4K: 4096x2160pixels
Frames Supported: 24P/25P/30P/50P/60P @4096x2160Pixel
24P/25P/30P/50P/60P @3840x2160Pixel
24P/25P/30P/50P/50i/60P/60i @1920x1080Pixel
Contrast: 1.000.000:1
Brightness: 1000 nits
Colors: 115% DCI-P3
Color Depth: 10-bit
Viewing Angle: 178 Degrees

GENERAL FEATURES

Monitor Features: Waveform
Focus Assist
Peaking
Zoom
False Color
Overlay - Scan Mode
3D LUT Support

MORE SPECIFICATIONS

Extras: SD Card for LUTs, Captured Images, Image Overlays.
Power: 3pin XLR DC input
2-pin Lemo DC input
USB DC output
USB-C
Power Consumption: 225Watt Typical/ 306Watt Max.
3-pin XLR --> (12-34V/12A)
2-pin Lemo --> (12V/2A)
USB 2.0--> (5V/2.4A)
USB C--> (5V/1.5A)
Country of Origin: USA
Warranty: 1 Year
