STATUS

Status

New

Availability

Available on order: 15 Business Days

Monitor Type

On Camera Monitor
On Camera Monitor

PANEL

Panel Size

7"
7"

Panel Type

LCD
LCD

Panel Resolution

Full HD 1920x1080pixels
Full HD 1920x1080pixels

Panel Aspect Ratio

16:9
16:9

Input Resolutions

SD 576i PAL(16:9)
SD 576i PAL(16:9)
SD 480i NTSC(16:9)
SD 480i NTSC(16:9)
HD 720: 1280x720pixels(16:9 aspect ratio)
HD 720: 1280x720pixels(16:9 aspect ratio)
HD 1080: 1920x1080pixels(16:9 aspect ratio)
HD 1080: 1920x1080pixels(16:9 aspect ratio)
UHD: 3840x2160pixels
UHD: 3840x2160pixels
4K: 4096x2160pixels
4K: 4096x2160pixels

Contrast

1300:1
1300:1

Brightness

3000 nits
3000 nits

Colors

1.07Billion

Viewing Angle

178 Degrees
178 Degrees

CONNECTIONS

Video inputs

3G/HD/SD-SDI (BNC) 1
3G/HD/SD-SDI (BNC) 1
HDMI 4K
HDMI 4K

Video outputs

HDMI 4K 1
HDMI 4K 1

No. of Audio outputs

1

GENERAL FEATURES

Monitor Features

Waveform
Waveform
Vectorscope
Vectorscope
Histogram
Histogram
Focus Assist
Focus Assist
Zebra
Zebra
Peaking
Peaking
False Color
False Color
Anamorphic
Anamorphic
3D LUT Support
3D LUT Support
Audio Meters
Audio Meters
Timecode Display
Timecode Display
HDR (high dynamic range)
HDR (high dynamic range)

MORE SPECIFICATIONS

Extras

USB-C for Camera Control

Power

Sony NP-F Type battery
Sony NP-F Type battery
USB PD input
USB PD input
DC input
DC input

No. of battery slots

1
1

Power Consumption

16Watt (DC 7-16V Input)

Country of Origin

China
China

Warranty

6 Months

PHYSICAL

Total Dimensions (LxWxH)

17.8 x 11.2 x 2.9 cm

Total Weight

409 gr
