Kramer Switcher

VS-44DT

MFR# VS-44DT/220V

in-Store Price: 4.067,55€ + VAT

Online Price: 3.904,84€ + VAT

HDMI? Matrix Switcher
4x4 4K inputs/outputs
4x HDMI 4K inputs
4x HDBASE T outputs

Not in stock
Available on order: 15 Business Days

VS−44DT is a 4x4 4K@60Hz (4:2:0) HDMI/HDBaseT matrix switcher that transmits video, audio, Ethernet, RS−232 and IR signals over extended distances. The unit accepts up to four HDMI and four IR inputs as well as Ethernet and RS−232 network and control. The inputs can be routed to any or all of the four HDBaseT outputs, the first two of which also have simultaneous HDMI outputs. VS−44DT connects to compatible HDBaseT receivers such as, TP−780RXR, TP−580RXR and TP−588D. It supports resolutions of up to 4K@60Hz (4:2:0) and WUXGA. The matrix is a PoE provider that provides power over Ethernet to compatible PoE receivers.

Max. Data Rate — 10.2Gbps (3.4Gbps per graphic channel).
Max. Resolution — 4K@60Hz (4:2:0) and WUXGA.
HDBaseT Range — Up to 130m (430ft) at normal mode (2K), up to 100m at normal mode (4K); up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using BC–UNIKAT cables.
Cables — For optimum range and performance, use the recommended Kramer cables available at www.kramerav.com/product/VS–44DT.
HDBaseT Extension — Includes Video, Audio, Ethernet, RS–232 and IR signals.
Outputs — 4 HDBaseT with outputs 1 and 2 having simultaneous HDMI outputs.
PoE Support — PoE provider to HDBaseT receivers such as the TP–588D and TP–780RXR.
HDTV Compatible.
HDCP Compliant.
EDID Capture — Copies and stores the EDID from a display device.
HDMI Support — 3D, Deep Color, x.v.Color™, Lip Sync, Dolby® TrueHD, Dolby Digital Plus, DTS–HD® and 7.1 PCM.
Non–Volatile Memory — Stores and recalls preset matrix configurations.
Automatic Output Shutdown — If no input signal is detected after a configurable idle period.
Kramer Protocol 3000 Support.
Lock Button — Prevents unwanted tampering with the settings.
Flexible Control Options — Embedded Web server, RS–232, IR remote (included).
Worldwide Power Supply — 100–240V AC.

Source: https://www.kramerav.com/product/VS-44DT

STATUS

Status: New
Availability: Available on order: 15 Business Days
Switcher/Router Type: 4x4

CONNECTIONS

Video inputs: HDMI 4K x4
Video outputs: HDMI 4K x2
Audio inputs: Embedded audio HDMI x4
Audio Output: Jack 3.5mm Stereo x1
8CH Embedded Audio HDMI x2
PC Connections: USB
Ethernet RJ-45
Other Connections: IR 3.5mm mini Jack

GENERAL FEATURES

Max Resolution Supported: 640x480pixels
SD 480i NTSC
SD 576i PAL
SVGA 800x600pixels(4:3 aspect ratio)
1024x768pixels(4:3 aspect ratio)
HD 720: 1280 x 720pixels (16:9 aspect ratio)
1280x1024pixels (5:4 aspect ratio)
Full HD: 1920 x 1080pixels (16:9 aspect ratio)
2K: 2048 x 1080pixels (1.89 aspect ratio)
Frames Supported: 50i/50P/60i/60P, 50HZ/60HZ
Rackmountable: Yes
