#name: "OG-FS-Mini"
#slug: "OG_FS_Mini"
#summary: "<ul><li>openGear PC Board </li><li> Frame Synchronizer </li><li> Up, Down and Cross Conversion </li><li> 3G-SDI IN/OUT & HDMI OUT </li><li> Up to 1920x1080pix? 50P/60P </li><li> 4:2:2 10bit Video sampling </li><li> Standard Ethernet Connection </li><li> High Quality</li></ul>"
#description: """
<div style="text-align: justify;">\r\n
\t<p>\r\n
\t\t<strong>OG-FS-Mini</strong> is an openGear broadcast quality utility frame sync that packs the production-proven reliability of AJA’s leading FS frame sync technology into an openGear card, supporting frame synchronization of untimed 3G-SDI, HD, and SD video signals at an affordable price. </p>\r\n
\t<p>\r\n
\t\tOG-FS-Mini allows users to synchronize and convert a wide range of video formats to their house standard with a 3G-SDI input and output, HDMI output, and two 3-pin terminal block connectors for balanced analog audio outputs. The OG-FS-Mini also provides high quality up, down, cross-conversion.</p>\r\n
\t<p>\r\n
\t\tOG-FS-Mini is designed for use in high-density openGear’s 2RU frames including AJA’s OG-X-FR frame. DashBoard software support on Windows®, macOS® and Linux offers remote control and monitoring of the openGear architecture and provides convenient and industry-standard configuration, monitoring and control options over a PC or local network.</p>\r\n
\t<br />\r\n
\t<strong>Features:</strong></div>\r\n
<ul>\r\n
\t<li>\r\n
\t\topenGear compatible card</li>\r\n
\t<li>\r\n
\t\tUtility frame sync function times input signals to an external reference</li>\r\n
\t<li>\r\n
\t\tSupports bi-level and tri-level references</li>\r\n
\t<li>\r\n
\t\tHigh quality 10-bit video processing</li>\r\n
\t<li>\r\n
\t\tLow latency processing, nominal video delay of 1 frame</li>\r\n
\t<li>\r\n
\t\tFreeze (on input signal loss) to black or last good frame </li>\r\n
\t<li>\r\n
\t\tSynchronizes 3G, HD and SD video formats</li>\r\n
\t<li>\r\n
\t\tSimultaneous SDI and HDMI outputs</li>\r\n
\t<li>\r\n
\t\t16-channel embedded SDI audio I/O</li>\r\n
\t<li>\r\n
\t\t8-channel HDMI output audio</li>\r\n
\t<li>\r\n
\t\t2x 3-pin terminal block connectors for analog audio output</li>\r\n
\t<li>\r\n
\t\tUtility frame rate conversion, supports 3:2 pulldown</li>\r\n
\t<li>\r\n
\t\tUp, down, cross conversion between 3G, HD and SD video formats</li>\r\n
\t<li>\r\n
\t\tAFD input detection, down-convert control</li>\r\n
\t<li>\r\n
\t\tRemote configuration through Ross DashBoard software</li>\r\n
\t<li>\r\n
\t\tRear I/O card included</li>\r\n
\t<li>\r\n
\t\tCompatible with OG-X-FR, OG-3FR and DFR-8321 openGear frames</li>\r\n
\t<li>\r\n
\t\tFive year warranty</li>\r\n
</ul>\r\n
<div style="text-align: justify;">\r\n
\t </div>\r\n
<div style="text-align: justify;">\r\n
\t<strong>NOTE:</strong> OG-FS-Mini supports 3G-SDI Level A only. 3G-SDI Level B is not supported. OG-FS-Mini passes-through embedded audio ancillary data only. It does not pass through other types of embedded ancillary data.</div>\r\n
<div style="text-align: justify;">\r\n
\t </div>\r\n
<div style="text-align: justify;">\r\n
\t </div>\r\n
<div style="text-align: justify;">\r\n
\t<strong>Simplified Block Diagram</strong></div>\r\n
<div style="text-align: justify;">\r\n
\t </div>\r\n
<div style="text-align: justify;">\r\n
\tOG-FS-Mini is designed to meet demands of broadcast engineering and live event production while providing incredible flexibility. It receives an untimed signal, frame syncs it, processes it and automatically routes it to both the SDI output for use in production and the HDMI output for monitoring. The user selects which 2-channels of audio are routed to the balanced analog audio monitor outputs.</div>\r\n
<div style="text-align: justify;">\r\n
\t </div>\r\n
<div style="text-align: justify;">\r\n
\t<img src="https://www.aja.com/assets/images/products/530/4573-og-fs-mini_diagram_thumb.jpg" /></div>\r\n
<div style="text-align: justify;">\r\n
\t </div>\r\n
<div style="text-align: justify;">\r\n
\t<strong>openGear Compatibility</strong></div>\r\n
<div style="text-align: justify;">\r\n
\t </div>\r\n
<div style="text-align: justify;">\r\n
\tThe openGear standard ensures that AJA cards will be compatible with other openGear products from certified openGear partners. With a growing list of products, openGear is the future of rackframe products.</div>\r\n
<div style="text-align: justify;">\r\n
\t </div>\r\n
<div style="text-align: justify;">\r\n
\t<strong>DashBoard Software</strong></div>\r\n
<div style="text-align: justify;">\r\n
\t </div>\r\n
<div style="text-align: justify;">\r\n
\tDashBoard software offers quick and convenient configuration and control of openGear cards on macOS, Windows, and Linux.</div>\r\n
"""
