Zoom Audio Mixer

LiveTrak L12 Next

MFR# L-12NEXT

in-Store Price: 636,25€ + VAT

Online Price: 610,80€ + VAT

Desktop 12-CH Audio Mixer
Built-in 14 Track Recorder
8x XLR/Jack 6.35 Combo IN
4x TS Stereo Jack 6.35mm IN

Not in stock
Available on order: 15 Business Days

Everything You Need, On Every Channel

In addition to 60mm faders, each channel has three multi-function encoder knobs, giving you analog style control of gain, EQ, compression, panning, and sends. No more scrolling through menus.

Significantly Upgraded Preamps

The L12next’s upgraded preamps deliver clean gain (+70dB), low noise (–128 dBu EIN), and full input flexibility with Hi-Z, PAD, and +48 V phantom power.

A Recorder for Every Session

The L12next has advanced recording features and captures up to 12 individual tracks at 24-bit/96 kHz, plus a stereo mix. Its new OLED screen streamlines recording controls and setup.

For Perfect Takes

Newly added features such as Overdub Mode and Auto Punch In/Out allow precise layering and easy re-recording. The new File Select button allows you to easily load additional tracks to expand your mix.

Your Final Mix is Ready

The L12next’s master channel captures your mix in 32-bit float for pristine, clip-free sound, while the master Compressor adds warm, natural compression that enhances the overall mix.

Monitoring Options

Five Personal Mixes

With five independent Monitor Outs, each musician can have a personal mix. Outputs support a stereo mix for headphones and in-ears, or a mono mix for stage monitors, making it flexible for live or studio use.

For the Sound Guy

The fifth monitor output is designed specifically for the engineer, letting them quickly monitor and adjust both the master and every custom mix. The built-in Talkback function makes it easy for everyone to communicate.

Custom Scene Recall

The L12next stores up to 10 scene memories, saving fader positions, EQ, pan, mutes and effects. Instantly recall mixes for live performances or recording in the studio.

LED Meters

The L12next’s LED meters show the volume level and encoder position for each channel. The new Fader Position button lets you quickly view saved fader positions when recalling scenes.

A Little FX Goes a Long Way

Enhance your sound with 16 onboard effects, such as delays and reverbs, with two easily accessible parameter controls.

Wireless Mixing Control

Control your mix wirelessly with the L12next Control app for iPad. Adjust faders, scenes, EQ, effects, and more.

*Requires the optional BTA-1 Bluetooth adapter. Wireless range up to 10 m in open spaces.

Audio Interface + Control Surface

The L12next is a 14-in/4-out USB audio interface for Mac, Windows, and mobile, supporting 32-bit float/96kHz recording and playback. You can record to your computer and SD card simultaneously, as well as control your DAW.

Stream Ready

Going live? The L12next integrates seamlessly with streaming software, making it the ultimate hub for podcasts, performances, and online broadcasts.

Hands-Free Control

Connect the optional Zoom FS01 footswitch to control key functions like effect mutes, punch-in/out, and playback.

Rackmount

The optional RKL-12 rack mount adapter lets you mount your LiveTrak L12next in any standard rack.

Source: https://zoomcorp.com/en/de/digital-mixer-multi-track-recorders/digital-mixer-recorder/livetrak-l12next/

STATUS

Status: New
Availability: Available on order: 15 Business Days
Audio Mixer Type: Desktop Audio Mixer
Desktop Audio Mixer
Digital/Analog: Digital Mixer
Digital Mixer
No. of Channels: 12
12

CONNECTIONS

No. of Audio inputs: 8/4
Audio Output: 3-Pin XLR Analog 2
3-Pin XLR Analog 5
Jack 6.3mm Phones
Jack 6.3mm Phones
PC Connections: USB2.0
USB2.0

GENERAL FEATURES

Phantom Power 48V: Yes
Yes
Digital Effects: Yes
Yes
No. of Digital Effects: 16(Delay-Reverb)
Busses: Yes
Yes
No. of Busses: Master: 1 Monitor: 5 SEND EFX: 1
Audio Meters: Yes
Yes
Peak indicator: Yes
Yes
Mount: Desktop
Desktop
Frequency Response: 20 Hz – 40 kHz ( -3.0 dB, 96kHz)
Audio Sampling Frequency: 44.1kHz
44.1kHz
48kHz
48kHz
96kHz
96kHz
Input Noise: 128 dBu Equivalent Input Noise

MORE SPECIFICATIONS

Extras: Recording media SD/SDHC/SDXC Card Up to 1TB (Class 10 or higher).
14x4 USB-C Audio Interface mode
Power: DC input 12V
DC input 12V
Power Consumption: 16W
Country of Origin: Japan
Japan
Warranty: 1 Year
